The Scorpion A2-Series line of motors was designed to be a premier high-performance power system for freestyle and UAV airplanes, delivering outstanding performance through exceptional efficiency.
By optimizing the rotor magnet design and utilizing premium 0.2mm silicon-steel stator laminations together with high-temperature enamel-coated copper windings rated above 200°C, Scorpion has achieved outstanding power density, efficiency, and thermal performance.
Combined with a robust design extensively tested by Scorpion's world-class team pilots, the A2-Series is engineered for excellent longevity, reliability, and performance.
The A2-10020-175KV was designed specifically for airplanes requiring approximately 120cc gasoline-engine equivalent performance using a 28-inch propeller on a 12S LiPo power system, as well as UAV and specialty aircraft requiring up to approximately 9500 watts of peak power.
* Continuous current is subject to power-percentage reduction factors. Peak power is intended for intermittent full-throttle operation ranging approximately 10-180 seconds depending on application and cooling. Refer to the Scorpion Motor Manual for additional information.
** Higher cell counts may be possible when using a smaller propeller.
