The Scorpion A2-Series line of motors was designed to be the optimal and premier choice of motor for freestyle and UAV airplanes, delivering outstanding performance through exceptionally high efficiency.
By optimizing the magnets in the rotor and utilizing premium 0.2mm-thick silicon-steel stator sheets together with high-temperature enamel-coated copper windings rated above 200°C, Scorpion has achieved exceptional performance and efficiency.
Combined with a robust design that has been extensively tested by Scorpion's world-class team pilots for longevity and reliability, the A2-Series is engineered to deliver exceptional power, efficiency, and durability.
The A2-10020-135KV was designed specifically for airplanes requiring approximately 120cc gasoline-engine equivalent performance using a 14S LiPo power system, or other airframes requiring up to approximately 9500 watts of peak power.
It can also be used as a lightweight electric power solution for certain 150cc-class airframes.
* Continuous current is subject to power-percentage reduction factors. Peak power is intended for intermittent full-throttle operation ranging approximately 10-180 seconds depending on application and cooling. Refer to the Scorpion Motor Manual for additional information.
** Higher cell counts may be possible when using a smaller propeller.
