Scorpion Tribunus III 06-160A ESC SBEC

Your Price: $289.99

Part Number: III_06_160

Availability: In Stock Free Shipping

Free Shipping

Quantity

Description

Specifications

Max Continuous Current	160 Amps
Peak Current	200 Amps
Operating Voltage Range	11-26.1 Volts
BEC Output voltage:	5.1V to 12.1V adjustable
Max Continuous BEC Output	15 Amps @ 8.1 V
Peak BEC Output	30 Amps/1s @ 8.1 V
On Resistance	0.37mOhms * 2
ESC Body Size	36.5 x 75.0 x 27.0 mm (1.44 x 2.95 x 1.06 in)
Mounting Tab Dimensions	24.0 x 84.0mm ( 0.944 x 3.30 in) / M3 Bolt
Weight (Without Connectors)	155g ( 5.47oz)
Drive frequency	8kHz - 32kHz

Included in the Box

1 x Tribunus III ESC
1 x 30mm Cooling Fan
2 x BEC Cables
1 x Mounting Hardware Pack
