In combination with our new A-Series motor line debut, we are also please to announce our new "PLUG-N-POWER" combo kits! We wanted to take the guess work, and customization out of using Giant Scale Electric Power Systems, and provide our customers with a simple, convenient and reliable power system for their 35cc-40cc sized airplanes. The A-5524 PNP Combo is the solution. This pairs our high power and high efficiency A-series motors along with our gas sized equivalent A-series Standoff and Cross Mount, with one of our suitably sized, pre-programmed, Tribunus ESCs! Providing you with a tested, proven, and convenient power system combo, which is sure to provide you immense power, at the best efficiency!
With 3D flight, low end torque and acceleration are crucial. Many companies opted to go with a “large diameter / thin height / high pole count motors" to try and get increased torque / acceleration. However doing this has the side effect of very large physical size and Lower Peak Efficiency. We at Scorpion have opted to stay with our proven 12N14P stator design. We have fine-tuned the magnets in the rotor to have amazing Peak Efficiency, and amazing Top End Power. Then, when used in combination with our Tribunus ESC, which has our proprietary drive algorithm which has unique switching pattern, along with features such as dynamic timing and dynamic frequency, we are still able to attain amazing low-end torque and acceleration. With the combination of the 2, we get “the best of both worlds” in the sense we have amazing peak Efficiency and Power with our stator design, and amazing low-end torque from the ESC side. Additionally, physically speaking our motors are similar length, with a much smaller outer diameter then other designs, which can be easier to fit inside cowls or fuselages of your airplane or UAV.
1 x Scorpion A-5524 BLDC Motor1 x A-55 Cross Mount (30cc-40cc) (Mounted)1 x A-Series Standoff Set (30cc-76cc) (Mounted) 1 x Tribunus II 12-80A ESC2 x Scorpion 410mm ESC/ BEC Cables3 x Scorpion Stickers3 x Prop Bore Spacers (8x10x 4/4/10)2 x M8 Nuts1 x Scorpion Backup Guard II (power board)
1455g
