The Scorpion A - Series line of motors was designed to be the most optimal and premier choice of motor for your freestyle or UAV airplane. We have achieved incredible performance through incredible efficiency. By optimizing the magnets in the rotor, and using the best quality 0.2mm thickness silicon steel stator sheets, and 2 x single strand 0.96mm enamel coated copper wire windings rated above 200C+, the performance and efficiency results are unlike anything we have seen before! Combined with a robust design which has been tested extensively by our world class team pilots for longevity and reliability, we feel this motor checks and exceeds all measurable categories!
The A-5524-205kv was designed for 74"- 78" Acrobatic Airplanes, or other Sport / UAV airplanes requiring up to 5000w of power on 12s battery.
Recommended Prop Selection :
21x12 / 22x10E / 23x8E
Recommended ESC : Tribunus III 14-150A ESC SBEC
Acrobatic Weight Range -: 6.2kg - 9.3kg (13.6lbs - 20.5lbs)
Sport / UAV (single engine) Weight Range : - 30kg - 40kg (66lbs -88lbs)
1 x Scorpion A-5524 BLDC Motor1 x A-55/65 Cross Mount (stock)4 x M4 Cross Mount Mounting Bolts3 x Prop Bore Spacers (8x10x 4/4/10)3 x Female 6mm Connectors3 x Heat Shrink3 x Scorpion Stickers2 x M8 Nuts
1g
